Sumitomo Bevel Buddybox – BBB4 Reducer

Right-Angle Spiral-Bevel Reducers with Cyclo Drive Input

BBB4 – rugged and durable speed reducer.

• Ductile iron housing for robust applications
• Low maintenance and easy to operate
• Highest reliability and durable design
• High efficiency, with all components made of high quality steel, hardened and ground

Bevel Buddybox – BBB4

The BBB4 gearmotor combines the strength and flexibility of the Cyclo Drive gear reducer and a single stage right angle spiral bevel gear stage in a rugged right-angle gearbox design. Its unique design combines performance with outstanding quality and reliabilty. Is is an excellent choice for applications in many industries including material handling & logistics, steel, chemical, waste water treatment, mining industries and operates savely in harsh and generally unattended ambient.

Key Facts

94 %

Efficient

18.000 Nm

Torque Capacity

75 kW

Max Rating

Features

Taper Grip Bushing System

The keyless Taper-Grip bushing system provides simple and reliable installation without the need for a custom shaft.

Ductile Iron Housing

New ductile-iron housing is twice as strong as cast iron, making it one of the most rugged bevel gearboxes available

Increased Overhung Load Capacity

BBB4 has over 375% overhung load capacity than previous models

New Larger Size

New F Size extends torque ratings up to 18.000Nm and can accommodate larger shaft diameters

Unified Lubrication System

Single oil-bath lubrication system for easy maintenance and higher performance.

Optional Taconite Seal System

Heavy-duty, fortified, grease purgeable system withstands the most demanding applications.
